Ornamental lighting fixture for parks and parking lots with 30-80W LED WB-BST-2000F-L
The ornamental lighting fixture for parks and parking lots WB-BST-2000F-L with 30-80W LED is ideal for:
- lighting parking lots private or public;
- lighting of alleys or access roads;
- lighting of parks and recreational areas;
- lighting of residential areas;
Optionally, in addition to the ornamental lighting fixture, a motion sensor can be mounted.
Product parameter (specification) of the 30-80w LED ornamental lighting
|
Product Code |
WB-BST-2000T/F-L |
|||||
|
LED Quantity |
24 LED |
24 LED |
32 LED |
36 LED |
32 LED |
36 LED |
|
Rated Power |
30W |
40W |
60W |
60W |
80W |
80W |
|
Color Temperature |
3000/4000/5000/6500K |
|||||
|
Luminous Flux |
2930lm |
3900lm |
5600lm |
5600lm |
7300lm |
7300lm |
|
Light Efficiency |
90-110lm/W |
|||||
|
Voltage/Frequency |
100-277V/50-60Hz |
|||||
|
Power Factor |
PF>0.9 |
|||||
|
Color Rendering Index |
>70 |
|||||
|
Installation Height |
4-10m |
|||||
|
IP Protection degrees |
IP66 |
|||||
|
IK Protection degrees |
IK10 |
|||||
|
Lamp Weight T/F:N.W (Kg) |
8.14/8.52 |
8.14/8.52 |
8.34/8.62 |
8.34/8.62 |
8.34/8.62 |
8.34/8.70 |
|
Warranty (Years) |
5 Years |
|||||
|
Packing Size |
455X455X610mm |
|||||
Product Features for the 30-80W LED ornamental lighting
Materials:
• Body: High-pressure die-cast aluminium.
• Protector: Super white tempered glass.
• Color: Any other RAL.
1. Special light ion-distribution lens, diffuser with super white tempered glass.Silicone gasket providing an IP 66 tightness level to the entire luminaire.
2. High strength die-casting aluminium heat sink, cast by 800T die-cast machine.
3. Electrical disconnector (immediate, automatic disconnection of the power supply) .
4. Silicone gasket providing an IP 66 tightness level to the entire luminaire.
5. Gear plate:Steel plate, Replacement of wiring plate without requiring tools.
6. Designed with a button-opening system that does not require any type of tool.
7. CREE XTE 24 LEDs for 30W/40W
8. CREE XTE 32 LEDs for 60W/80W
9. CREE XTE 36 LEDs for 60W/80W
